  1. Proteksan & Turquoise completes 53-meter trawler "Vinydrea"


    The trawler yacht with steel hull and aluminum superstructure, capable of undertaking voyages of discovery across the world’s oceans, has been styled and designed by Paolo Caliari with the contribution of the shipyard’s own naval architects.

    Jean Guy Verges has designed the interior; which will feature accommodation for 12 guests and as many crew. Built to ABS class and fully MCA compliant, the yacht will achieve 16 knots powered by twin Caterpillar 3512B engines, each producing 1,750hp. Her fuel-carrying capacity of 100,000 liters ensures that she will not need too many pit stops along the way.

    Starting from hull lines, it can be immediately seen that the design is adapted to her world class standard giving her efficiency, seaworthiness and safety while cruising in rough seas due to her well flared high bow. Deck spaces are generous for outside entertainment.The bathing platform aft of the transom is fully integrated and well finished with teak decking details.

    The hydraulic transom door opens into a large lazarette where the main tender is stored, which can be lifted by the concealed “passa-crane”, that has three functions; crane for tender, gangway and swim ladder with self-leveling stair. When it is used as a swim ladder, it allows to go down the sea as if going down a beach.

    One of her essential characteristics is the asymmetrical main deck design, which may be noticed at first sight. Extra volume for large and comfortable lounge is achieved by having side deck only on port side. Thanks to her well-designed layout, she has 30% more volume, compared to other yachts of similar length available on the market.

    The lower deck has four guest staterooms and one full beam VIP suite. The VIP has a lounge area and a walk-in wardrobe as well as large suite facilities with jacuzzi and shower, while the three with large double-beds and the one with twin bed all have shower rooms.The spacious spaces are divided with large rationality: the crew quarter located forward the guest area is strictly separated, but converging in strategic points of the boat. The crew quarters are large and well appointed with their private dining area and service galley as well as entertainment center. Five double cabins with private heads. A hidden door gives access from the crew quarters to the guest area for service purposes.

    The deck below the crew houses the laundry as well as storage space and the technical room. The aft main deck reflects the completely different approach that this boat brings being unusually over-sized with its large pool/spa with glass waterfall wall to aft and flanked with a pair of large stairways with led type night-lighting steps leading to the bathing platform that becomes a giant terrace and boarding deck nearby the sea while the transom door is in open position giving also access to the huge garage housing all necessary toys and diving equipment.

    The aft main deck also offers a large lounge area fitted with a comfortable outdoor sitting area covered by the upper deck creating a welcoming place for the visitor or relaxation in the evening. It opens through automatically operating sliding doors giving way to the main salon with its area of 100 square meters. The large side windows offer ample natural light to the interior and scenic views to the outside. They offer also a real feeling of floating above water. A sliding door leads to the main lobby where the day head is located. A sliding door to port gives access to the pantry connected to the main galley while the elevator and main staircase connects all levels.

    On the port side companionway reached through the service door, the main galley is fully equipped with professional stainless steel appliances, oversized food storages and large cold room sets. Wall cabinets provide ample additional storage. A set of three windows brings natural light to this galley giving it an open and airy feeling. Still on portside forward a private entrance leads to the lower crew quarters while an external stairway gives direct access to all the upper decks.

    Forward of the main lobby the wide body space is reserved for the owner’s suite. A private lounge and study room lead on portside the oversized walk-in wardrobes which provide ample room for long range cruising. One unique feature of the owner’s quarters is the private forward deck. The master suite area is full beam with floor to ceiling windows that enhance feeling of open space by bringing plenty of natural light. A panoramic view is ensured in the owner’s bath thanks to the large windows. The master suite open to a forward deck terrace and an airplane type electro hydraulic automatic stair opening from the bonnet allows to go up from this terrace to above decks front part.

    The upper deck can be reached either with the elevator or the central staircase from the main deck lobby as well as connecting the lower deck too. The upper deck is walk-around giving access forward to the wheelhouse port & starboard side entrances and further to the bow via a gated central companionway. Pair of external starboard/portside stairways are reaching the flybridge as well. The upper deck has a captain’s cabin behind the wheelhouse. Behind the captain’s cabin the large pantry is located to serve the panoramic dining room, lounge and the aft deck.

    The round sliding door system provides an interior and exterior dining facility depending on weather conditions. Alfresco dining is available under the hardtop as well as the fully equipped pantry with food lift. The forward area is devoted to a very large Jacuzzi surrounded by sun-pads protected by the wrap-around windshield, while at center takes a place the huge gymnasium and health SPA cabin. An electrical retractable awning can be deployed to shade the deck area. Teak decking gives the final touch.

    Specifications:

    Overall Length : 53.20 M
    W.L. Length : 48.60 M
    Beam O.A. : 9.40 M
    Draft : 2.90 M
    Displacement : 620 tons
    Propulsion : 2x CAT 3512B B-rating HD 1750 BHP@1600 RPM
    Max Speed : 16 Knots
    Fuel Capacity : 100 m³
    Electricity Generation : 3x86 ekW CAT
    Range : 4400 nm @ 13.4 knots
    Construction : Steel Hull & Aluminum Superstructure
    Builder: Proteksan & Turquoise
    Year: 2008

    For more information:

    Proteksan & Turquoise,
    Mahir Iz Cad. No:28,
    34662 Altunizade,
    Istanbul/ Turkey.
    Telephone : +90 216 474 25 90-91
    Fax : +90 216 474 25 95
    http://www.proteksan-turquoise.com

    ***​
