Cabo 40 generator exhaust

Discussion in 'Cabo Yacht' started by Breckster, Dec 7, 2019.

You need to be registered and signed in to view this content.
  1. Breckster

    Breckster Member

    Joined:
    Aug 22, 2013
    Messages:
    46
    Location:
    Bay City
    QUESTION: Where does the raw water exit the boat after passing through gen. heat exchanger. I noticed that the generator exhaust is "dry" when it exits boat port-side amidship. I immediately shut down generator believing it was not pumping water but was later told it exits under boat as to create a "vacuum" while underway? Westerbeke 12.8 on a 40 Csbo convertible..

    thank you for answering.. the manual states nothing about this and drawings of through-hull(s) do not indicate where.
  2. Capt Ralph

    Capt Ralph Senior Member

    Joined:
    Sep 8, 2004
    Messages:
    9,826
    Location:
    Satsuma, FL
    You have an exhaust water separator. After the muffler, there is a second box that separates the cooled exhaust gases above the water line. The hot water is released below the water line. Makes for a very quiet exhaust system. No splashing or gurgling is heard.
    The back side, you can not see how much water the raw pump is moving. Train you ear, when it gets loud, impeller time is near.
    I don't know of any vacuum. Our friend just south of me (CSkipR) may chime in. Similar ship I believe.
    Last edited: Dec 7, 2019
  3. Capt J

    Capt J Senior Member

    Joined:
    Jul 11, 2005
    Messages:
    13,936
    Location:
    Fort Lauderdale
    Follow the hose from where it exits the side of the boat, it exits below the waterline, like 2' down/in from the muffler through a seacock.
  4. Breckster

    Breckster Member

    Joined:
    Aug 22, 2013
    Messages:
    46
    Location:
    Bay City
    thanks guys.. i was, at first very concerned of no water exiting exhaust (like my 37 Bertram did) and shut it down. Later on, it was verified that indeed it was getting water and expelling it overboard as designed. "New" boat to me as well as new brand.. trying to grasp systems from afar with only short trips to visit my new "mistress" :)

    BTW: a very different boat compared to my bertram w/Detroits, which felt like a "over-built tank".
  5. Capt J

    Capt J Senior Member

    Joined:
    Jul 11, 2005
    Messages:
    13,936
    Location:
    Fort Lauderdale
    The cabo is a great boat and the 40' is one of their best running hulls. I've run a lot of them. They like some trim tab at cruise speed. Is yours an express or Flybridge, what engines?
  6. Breckster

    Breckster Member

    Joined:
    Aug 22, 2013
    Messages:
    46
    Location:
    Bay City
    2007 Flybridge w/Man CR-800's.. i noticed, it did not need as much tab down as did my 37, very "nimble" feeling and pleasure at cruise
  7. Capt Ralph

    Capt Ralph Senior Member

    Joined:
    Sep 8, 2004
    Messages:
    9,826
    Location:
    Satsuma, FL
    Ya know I'd chime in on that, Ole Bertrams are overbuilt tanks...
    <--
  8. Capt J

    Capt J Senior Member

    Joined:
    Jul 11, 2005
    Messages:
    13,936
    Location:
    Fort Lauderdale
    I just delivered that same very boat from Fort Lauderdale, FL to Fernandina Beach, FL and loaded it on a freighter bound for Bermuda. I've run at least 7 different 40' FB's and around 300 Cabo's of all sizes.
  9. Beau

    Beau Senior Member

    Joined:
    Jan 15, 2010
    Messages:
    2,266
    Location:
    Beaufort, NC
    and so, your conclusions....
  10. Capt J

    Capt J Senior Member

    Joined:
    Jul 11, 2005
    Messages:
    13,936
    Location:
    Fort Lauderdale
    The Cabo 40' is an extremely well built boat and great running and I know most all of the ins and outs of the entire Cabo lineup.
  11. bayoubud

    bayoubud Senior Member

    Joined:
    Feb 19, 2017
    Messages:
    1,017
    Location:
    Florida
    Was with a friend looking at one. The broker was familiar with Cabo, said it was the best riding hull they built, deep V I think.
  12. Pascal

    Pascal Senior Member

    Joined:
    Feb 29, 2008
    Messages:
    6,574
    Location:
    Miami, FL
    I d like to install an air water sep on my Hatt as the exhaust is released amidship with a fairly loud and powerful spray I hate not to see the actual water discharge though and wonder about discharging the water a few inches above WL, just like air con water. It doesn’t make much noise in the first place. Plus, that s one few below WL hole...
  13. Capt Ralph

    Capt Ralph Senior Member

    Joined:
    Sep 8, 2004
    Messages:
    9,826
    Location:
    Satsuma, FL
    My last Gas-sep install, I did install the water outlet a couple of inches below the boot. Not by design but the only place available. Depending on loading, the water discharge is just below or half at the water line.
    You can not hear any water flow or splash but you can see the out flow. Turned into a great end result.

    All 2" hose and fittings. Centek muffler and gas-sep. 20KW NL gen-set in a NL sound box.
  14. PacBlue

    PacBlue Senior Member

    Joined:
    Jan 9, 2009
    Messages:
    1,997
    Location:
    Dana Point, Ca
    They work great a few inches above the waterline and you usually get a nice steady stream of water without the pulsating of the exhaust gases so it it less annoying and still allows you to have a handy visual aid on your gensets raw water cooling flow.
  15. PacBlue

    PacBlue Senior Member

    Joined:
    Jan 9, 2009
    Messages:
    1,997
    Location:
    Dana Point, Ca
    Glad to see you have a new ride, I am sure she will be kept just as pristine as your Bertram, congratulations!

    There are a few really knowledgeable and hands on 40 Cabo owners on this site who can get you up to speed, happy boating :)
  16. Breckster

    Breckster Member

    Joined:
    Aug 22, 2013
    Messages:
    46
    Location:
    Bay City
    thank you for all the replies.. looking forward to getting familiar with her. i reside in Michigan and will be making the trek back north with her throughout the winter. At current she is in Stuart awaiting some work at A&J's and then the plan is up to Wilmington, NC until the ice is gone in the erie canal/great lakes. Hopefully i'll have a few chances to utilize her this winter??
