1968 Chris Craft 37' Roamer Wiring Diagram Sought

Discussion in 'Chris Craft Roamer Yacht' started by lacabina, Dec 2, 2016.

You need to be registered and signed in to view this content.
  1. lacabina

    lacabina Member

    Joined:
    Dec 3, 2004
    Messages:
    40
    Location:
    woodstock georgia
    The Mariner's Museum is closed for renovations. I am seeking a wiring diagram of the 12 volt system for my boat. A fire in the wiring harness leading to the flybridge necessitates a complete re-wire. Hard to do without a diagram. Any help would be appreciated. Perhaps even a similar size and year in the Commander series?
    Thanks
  2. Roamer Blue

    Roamer Blue New Member

    Joined:
    Dec 21, 2016
    Messages:
    3
    Location:
    Toronto ON
    watching... wrong time to be starting a refurbishment on the same boat.

    RB
  3. alloyed2sea

    alloyed2sea Moderator

    Joined:
    Jan 28, 2004
    Messages:
    850
    Location:
    Alex, VA
    Actually have one for my '67 Riviera 37 Express from them, but it's really big size-wise.
    Mine was for 327s (original motors), no flybridge.
    Will endeavor to dig it out,...

    Attached Files:
