3412e glazing???

Discussion in 'Engines' started by Millennium, Sep 12, 2011.

You need to be registered and signed in to view this content.
  1. Millennium, Sep 12, 2011
    #1
    Millennium

    Millennium New Member

    Joined:
    Sep 12, 2011
    Messages:
    3
    Location:
    Fremantle
    Hi I have a cat 3412e that is rated at 1300hp in a planing speed commercial fishing boat I have been operating this in at low rpm . I am concerned that I have glazed up my cylinder walls. 3 questions
    Am I damaging my engine ?
    How can I fix this problem?
    Is there a way I can continue to operate at very low rpm without a reacurrance of this issue?
  2. Marmot, Sep 12, 2011
    #2
    Marmot

    Marmot Senior Member

    Joined:
    May 20, 2007
    Messages:
    3,311
    Location:
    9114 S. Central Ave
    Why do you think you may have glazed the cylinders? Is the engine hard to start? Lots of blowby? Smokes?

    If none of the above are indicated but you still can't sleep at night, take 2 aspirins and run them up to speed for a few moments each hour or two.
  3. K1W1, Sep 12, 2011
    #3
    K1W1

    K1W1 Senior Member

    Joined:
    Sep 30, 2005
    Messages:
    7,394
    Location:
    My Office
    Hi,

    I agree with Marmot.

    I also have to ask if this is a commercial game boat or commercial fish boat.

    If the latter it makes me wonder why it was setup with a highly strung engine in the first place.
  4. Pascal, Sep 12, 2011
    #4
    Pascal

    Pascal Senior Member

    Joined:
    Feb 29, 2008
    Messages:
    8,164
    Location:
    Miami, FL
    the boat i run has 3412Es rated at 1400hp. we often run a hull speed, especially on the spring/fall trips up and down the coast and so far so good at 3000hrs. I always run on plane for 15 to 30 minutes at the end of a long slow days
  5. Capt J, Sep 12, 2011
    #5
    Capt J

    Capt J Senior Member

    Joined:
    Jul 11, 2005
    Messages:
    14,435
    Location:
    Fort Lauderdale
    The CAT 3412's are pretty good at metering fuel at lower rpm's. However, I would run the engine at cruise for 30 minutes every 6 hours just for peace of mind, or at least at cruise for 30 minutes right before you get to the dock. If you do bring it up to cruise after running at slow speeds for a long period of time, what does the exhaust look like? Is it clean, a little smokey, very smokey, how long does it take to clean up if it is very smokey?
  6. Millennium, Sep 13, 2011
    #6
    Millennium

    Millennium New Member

    Joined:
    Sep 12, 2011
    Messages:
    3
    Location:
    Fremantle
    Thanks for the speedy replies guys what a great resource you all are. The boat is a 20m aluminum planing vessel capable of 30 knots, but because of catch restrictions in our lobster fishery I have been operating in the deep sea crab fishery as well traveling long distances with full tanks where cruising at 20knots is not an option. The main reason I think I have glazing is the poor fuel economy Im getting when I operated the boat at normal cruising revs. Also the engine mis firing on start up unless I crack the throttle a bit. Are these fuel and oil additives that claim to reverse the glazing the real deal?
    Thanks again
  7. Millennium, Sep 13, 2011
    #7
    Millennium

    Millennium New Member

    Joined:
    Sep 12, 2011
    Messages:
    3
    Location:
    Fremantle
    There is a fair bit of smoke at start up but after that nothing unusual.
  8. K1W1, Sep 13, 2011
    #8
    K1W1

    K1W1 Senior Member

    Joined:
    Sep 30, 2005
    Messages:
    7,394
    Location:
    My Office
    Hi,

    What is a usual amount of smoke?

    Do you get much blowby ( crankcase pressure) when she is running?

    Does it burn any Lube Oil?

    Do you find anything unusual in your Oil Samples?

    If it misses only at startup and smokes a bit till it warms up some I would say it doesn't have much to do with glazing but is more likely a carbon buildup on one or more of your injectors that makes things a bit rough at get go. The smoke and rough running could also be from a leaking nozzle or two dropping fuel onto the piston crowns that takes a bit to get going when she flashes up.
  9. Pascal, Sep 13, 2011
    #9
    Pascal

    Pascal Senior Member

    Joined:
    Feb 29, 2008
    Messages:
    8,164
    Location:
    Miami, FL
    Define poor economy? Do you have fuel glow data, how much are you burning at what speed and what RPM

    First thing to check is condition of hull and running gear

    When you say misfire, do you mean hunting? Rpm going up and down a bit before settling?

    Obviously in cold weather you ok have more smoke at startup
  10. K1W1, Sep 13, 2011
    #10
    K1W1

    K1W1 Senior Member

    Joined:
    Sep 30, 2005
    Messages:
    7,394
    Location:
    My Office
    Hi,

    You might also want to have a look at this to remove some myths.

    Bore glazing
  11. Old Phart, Sep 13, 2011
    #11
    Old Phart

    Old Phart Senior Member

    Joined:
    Mar 14, 2011
    Messages:
    1,332
    Location:
    I dunno
  12. Capt J, Sep 13, 2011
    #12
    Capt J

    Capt J Senior Member

    Joined:
    Jul 11, 2005
    Messages:
    14,435
    Location:
    Fort Lauderdale
    You might benfit from a good fuel additive like Diesel Kleen.
  13. K1W1, Sep 13, 2011
    #13
    K1W1

    K1W1 Senior Member

    Joined:
    Sep 30, 2005
    Messages:
    7,394
    Location:
    My Office
    Hi,

    I would say that your link would be far more expensive than re lining the engine.

    If you have some personal grievance with what ever I post take it up with me by PM or talk to Carl, don't pollute and degrade the forum with trash posts giving other members crap and or misleading advice.
  14. Old Phart, Sep 13, 2011
    #14
    Old Phart

    Old Phart Senior Member

    Joined:
    Mar 14, 2011
    Messages:
    1,332
    Location:
    I dunno
    Not a good Internet response to prior link.
    Hope this helps:

    Google’s links for Bore Glazing

    Google

    P.S.- Obviously, the first return (coxengineering.co.uk) is not of help, currently.
  15. Bamboo, Sep 13, 2011
    #15
    Bamboo

    Bamboo Senior Member

    Joined:
    Dec 19, 2008
    Messages:
    934
    Location:
    Palm Beach, FL
    Your first link is a dead link- does that qualify as trash or misleading advice? :D
  16. YachtForums, Sep 13, 2011
    #16
    YachtForums

    YachtForums Administrator

    Joined:
    Dec 22, 2002
    Messages:
    20,378
    Location:
    South Florida
    Gents,

    I'm a little overwhelmed of late with YF upgrades and GF downgrades, so please give me a break and give yourself a break... if you can't say something nice, don't say anything at all. That phrase is something I've become intimately familiar with recently.

    PLEASE... stop sweating the small stuff. It's a HUGE turn off for YF followers and frankly, it's unbecoming of the quality of people that inhabit this forum.

    Carl
  17. K1W1, Sep 14, 2011
    #17
    K1W1

    K1W1 Senior Member

    Joined:
    Sep 30, 2005
    Messages:
    7,394
    Location:
    My Office
    Hi,

    Apologies for posting a duffer, it did work when first posted but doesn't from here now.

    This is where I found it though.

    bore glazing - Google Search
  18. Bamboo, Sep 16, 2011
    #18
    Bamboo

    Bamboo Senior Member

    Joined:
    Dec 19, 2008
    Messages:
    934
    Location:
    Palm Beach, FL
    Super... thanks for the working link!
