Lightning

Discussion in 'General Yachting Discussion' started by CaptEvan, Apr 17, 2009.

You need to be registered and signed in to view this content.
  1. CaptEvan

    CaptEvan Senior Member

    Joined:
    Aug 15, 2006
    Messages:
    172
    Location:
    Great Lakes
    Sorry Capt. Bill for not responding to your question. The Volvo IPS triple engine system on the boat had 19, and we added 2 of our own. Come to think of it, the G-Series has a few more, so we might have been 25 plus.

    When I inquired, at a Volvo IPS training session, of the ability to get an engine running after a lightning strike 30 miles out, the instructor gave the canoe paddling motion. But with fuel delivery in most current engines controlled by printed circuits, baling wire and duct tape simply will not get you home anymore.
  2. antiguogrumete

    antiguogrumete New Member

    Joined:
    Feb 26, 2010
    Messages:
    133
    Location:
    Alicante, Altea Spain
  3. NYCAP123

    NYCAP123 Senior Member

    Joined:
    Mar 14, 2008
    Messages:
    11,205
    Location:
    Long Island, NY
    That's why I love sailboats (not to be in, but to have around in a storm).:)
  4. tirekicker11

    tirekicker11 Senior Member

    Joined:
    Jul 29, 2010
    Messages:
    322
    Location:
    SE Asia
    I have been hit by lightning twice on a delivery of a 44' Lagoon from France to Annapolis. I was at the Flying Bridge about 4 meter from the mast foot (shouldn't have been there in hindsight) and one of my crew was lying on the couch in the saloon looking outside trough a roof hatch.

    We knew we were going to be hit becouse the lightning had surrounded us and was closing in on us. When it finally hit I fended my eyes of and heard a loud bang with white light. The crew member lying on the couch remembers seeing the lightning hitting the mast. This happend twice that night and our only damage was the VHF antenna.
  5. saltysenior

    saltysenior Senior Member

    Joined:
    Aug 22, 2009
    Messages:
    289
    Location:
    stuart,fl.
    no one can figure out lighting....maybe 50% fact,50% guesswork....we where hit in MD.one summer and i spent the next 9 years researching and talking to other victims...found out nothing that could be put in stone,except be lucky........examples...2 same type small boats,on different occasions,where hit in palm beach inlet...#1,all safe,but burnt a little...#2,all dead...............a small sportfish,w/very short riggers,docked between two large sailboats at elbow key..he gets hit in his searchlight,wipes out his electronics,and no one else has any sign of a hit..........riding back from west end in the worst lighting storm..antennas and long outriggers..we can see lighting hitting the water many times very close, but it never hit us ????? be lucky
  6. Capt J

    Capt J Senior Member

    Joined:
    Jul 11, 2005
    Messages:
    14,432
    Location:
    Fort Lauderdale
    There's no ryhme or reason. Except certain boats seem to attract it more then others. I know of 2 sportfish that were both hit 3 different times. 1 of them docked in a crowded marina with other tall antannae's and metal structures all around it, yet it got hit 3 different times over a few years. Don't know why, but none of the other boats or the fuel dock and it's equally tall metal sign never got hit. Maybe the electrical field a combination of a yachts metal and electronics attract it, I don't know.
  7. Grecko

    Grecko New Member

    Joined:
    Jun 27, 2009
    Messages:
    50
    Location:
    Presently landlocked
    The aviation industry has been dealing with this issue for some time. If an aircraft with a FADEC (full authority digital electronic control) on the engines were to be hit by lightning, things would go quite, and in an airplane that's a "very bad thing".

    Do a search on HIRF and HIRF/L protection and you will see how this is done with aircraft.

    Basically what is done is each piece of electronics is "hardened" by putting it into a box that is grounded and has no holes in it. All of the cabling is shielded and the shielding is grounded and the cabling connectors are metal and are grounded to the shielding and the case. Lengths of cabing that are not shielded and grounded act like antennas and pick up the lightning, so you don't want unshielded runs of cable anywhere in the boat.

    It can be done, the radios and electronics in aircraft are hardended, but it is expensive and since it happens infrequently and the effects aren't usually life threatening, electronics in boats aren't hardended. There is testing that can be done, and the FAA and the military have standards for the protection of hardware, but as I've said it costs a lot to make the hardware hardended, and the engineering and testing aren't cheap either.

    My concern would be with electronic engine controls. A lightning strike would leave you dead in the water and when you are offshore, that's just a bad place to be.
  8. islandmech

    islandmech New Member

    Joined:
    Jul 13, 2010
    Messages:
    9
    Location:
    Victoria B.C.
    There was an excellent article in PassageMaker magazine recently about lightning. It describes a new system being installed on a 40 ft boat which routes the charge down to a series of discharge ports along the water line of the boat. {Very similar to static wicks on an aircraft}
    I don't have the info with me but a check of PassageMaker online might bring up the article.

    Cheers
  9. 'RoundTheHorn

    'RoundTheHorn Senior Member

    Joined:
    Oct 6, 2004
    Messages:
    273
    Location:
    Salish Sea
    It was the July/August 2010 issue on pages 44 to 53. The company mentioned is Marine Lightning Protection - http://www.marinelightning.com.
  10. sharkbait

    sharkbait New Member

    Joined:
    Sep 10, 2011
    Messages:
    48
    Location:
    taree
    to my knowlegde it is like a lightning strike on a tree. the sap vaporizes and expands instantainously causing the tree to explode.

    As the concrete holds moisture it has same effect - vaporises, expands, explodes (when structure fails to withstand the pressure).

    My question would be "what is the effect on a steel hull boat with a alloy mast"

    I know the mast would melt but
    the discharge to the lowest potiental and
    what path it would take,
    along with how well earthed you are inside all would affect whether you get fried or not?

    I dont know....
    I would be interested if any1 had a answer to
    will you get fried in a steel hull boat or will the water act as a strong enough insulator to allow survival?
  11. sharkbait

    sharkbait New Member

    Joined:
    Sep 10, 2011
    Messages:
    48
    Location:
    taree
    Sorry people.
    I just read the post here by Captin Tom
    I wish to agree with every thing he has stated BUT
    lightning must be thought of as potiential difference not pos and neg...
    A HIGH POTIENTIAL DIFFERENCE will discharge to a LOW POTIENTIAL DIFFERENCE. a high charge will go to a low charge potiential.

    Lightning can BOTH-
    discharge from the sky/clouds to a ground or
    discharge from the GROUND TO THE SKY/clouds.

    lightning from clouds to earth- can be caused by smoke particals, dust/dirt, polution, the lists are endless, these bolts are caused by a static build up from friction between these particals, think of this as a "positive ion generator" or high potiential.

    Lightning earth to sky- can also be caused by water molecules rubbing against each other as a "ion generator" (like a waterfall) or low potiental.
    or
    a high potiental has discharged too much and has become a low potiental.

    the reason positive and negitive is not used in the description is the charge in a circuit does not flow from pos to neg as most think... it flows from neg to pos. lol
    it wasnt descovered untill the age of necular study and it was too expensive & too much hassel to change the text books and teachings untill receint times.

    why it hits some boats and not others could be the depth of its keel compared to the others around it, if this isnt right then resistance or some other factor may be at play... i would have to think about it further and know more about the conditions surrounding it all.

    hope this helps your understanding.

    IF you wonder about my question in the other post about this subject...
    I think I know the answer but having a second oppinion will never hurt and can save a life or two.
  12. CaptTom

    CaptTom Senior Member

    Joined:
    Jan 26, 2006
    Messages:
    1,949
    Location:
    Palm Beach to Ft Lauderdale
    Sharkbait, thanks for sharing your comments.
    Well, pos to neg, neg to pos, from or to the clouds, all I know is that lightning is probably the scariest thing a mariner has to deal with.
    But it makes for nice pictures.

    Attached Files:

  13. sharkbait

    sharkbait New Member

    Joined:
    Sep 10, 2011
    Messages:
    48
    Location:
    taree
    too true capt.
    I hope it helps, it not a easy subject.
  14. ArcanisX

    ArcanisX Senior Member

    Joined:
    Jul 22, 2009
    Messages:
    313
    Location:
    Tel Aviv.
    A huge deal is the way a whole grounding assembly is installed.

    When lightning strikes even a working "protection" (e.g. anthena - cable - grounding), the whole assembly is subject to some serious electricity. And that in turn generates all kinds of secondary effects (powered cable generates some electromagnetic field. When the "power" is those of a lightning, that field is no joke either.) Hence it could still fry stuff around even without "body of lightning", pardon layman's terms, hitting anything but designated route. That's why EM shielding is useful, and distance is a good start at that (e.g. if your lightning-catcher antenna is too close to your radio antenna, EM will cause "secondary spike" in radio circuit, which while weaker then original could still well be enough. Same's gonna happen if grounding cable is laid in unshielded proximity of other wiring.).

    By the same virtue it is critical that all components used are on the excessive side - if cable's too "thin", it will work the same way heating spiral in your toaster does when subjected to lightning strike, with the body of yacht playing toast.
  15. sharkbait

    sharkbait New Member

    Joined:
    Sep 10, 2011
    Messages:
    48
    Location:
    taree
    sorry people'
    spoke to my dad (electrical engineer) who said to strike out the positive and negitive ion terms i used in my post... apart from that it is right...

    I do agree with Arcanisx there is enough high voltage and amperage to cause a mini EMP (electro magnetic pulse).
    dad is not sure if there is any way to protect any modern electronics.
    to his and my knowledge all military electronics which could be exposed to a EMP are protected by using the old tube technology (tubes are same as those found in very old radios and tvs), these tubes are impervious to EMP's unlike all IC's versions etc... (the reason tubes are still manifuctured).

    I suppose if you use a faradays cage over the electronic device it may protect it. but this has many factors as well.
  16. sharkbait

    sharkbait New Member

    Joined:
    Sep 10, 2011
    Messages:
    48
    Location:
    taree

    Attached Files:

  17. Berean

    Berean Senior Member

    Joined:
    Aug 26, 2007
    Messages:
    305
    Location:
    Sarasota FL
    I know this is an older thread, but I live in the Tampa Bay Area so it is relevant. This time of year there are weeks where I am confronted with the possibility of a lighting strike almost daily. Lightning is the one thing that scares the heck out of me. Over the years I have been on several boats that have endured a direct hit. Almost all had significant electronic damage. The most scary however was a few summers ago as I was coming into Venice inlet through a squall there was a loud CRACK BANG and an "arc" of electricity (?) from my Morse throttle lever to my hand inches away. Scary but I was not hurt. But it has left an impression on me, and has not helped my image of lightning.

    But it is not the damage to electronics that is my biggest concern, it is the safety of the crew, passengers and myself. For those who operate from a flying bridge as I do (enclosed with or without tower), what do you do when it is inevitable you will be in a squall? Do you stop the boat and go down below until the threat passes? Or do you continue on and hope for the best?

    I ask because most of the charter fishing boat capts in the area seem to run right through these squalls from their FBs with apparently little regard to the risk of a strike. I cannot count the times I have been confronted with this decision. Could it be that tubular metal (stainless, aluminum) serves as a Faraday Cage?

    I would really be interested to know what other capts do in this situation.

    Thanks!

    John
  18. NYCAP123

    NYCAP123 Senior Member

    Joined:
    Mar 14, 2008
    Messages:
    11,205
    Location:
    Long Island, NY
    Run like hell and hope for the best. I certainly won't leave a boat floating with nobody at the helm. One good thing about Florida weather is that it's often small cells that you can run between or around. Even though lightening can travel a long distance, it at least lowers your risk. As for the charter fishing captains, they're a breed onto themselves. They understand fish and the paycheck at the end of the run. Not much else in life matters (At least when they're out).
  19. Berean

    Berean Senior Member

    Joined:
    Aug 26, 2007
    Messages:
    305
    Location:
    Sarasota FL
    No, I wouldn't leave a boat essentially "NUC" not under command either. But...what about anchoring? Especially in a slow boat like mine...

    Is anchoring something some would do in lieu of running an electrical gauntlet?
  20. Capt Bill11

    Capt Bill11 Senior Member

    Joined:
    Feb 27, 2006
    Messages:
    1,458
    Location:
    Sarasota/Ft. Lauderdale FL
    I helped manage and maintain a fleet of GBs in Sarasota for 15 years and none of them were ever hit by lightening. So the odds at least are in your favor. Then again, maybe not based on your history. :)

    But seriously, about all you can do is set up a lightening rod at the highest point on your boat, attach a very heavy cable to it and run it to a large bonding plate located on the underside of your hull. To be truly effective the rod has to be high enough to create a "cone of protection" over and around your boat.

    I would only recommend anchoring as a strategy if you saw on radar that the storm was moving away from you or you were moving in to a storm that was passing by. If you don't have radar on your boat look into one of the real time radar apps for your smart phone if you have one.
