Remodelling Job

steveinjeddah · 10-22-2009, 09:13 AM

I'm the Captain of a 38m motor yacht built in 1996. I'm trying to get the owners interested in remodelling the front of the wheelhouse. Removing the heavily-raked windows and replacing them with vertical windows (or near-vertical). The problem is trying to visualise what it will look like.

I'm looking for someone to modify the attached image to bring the windows vertical and to carry the wheelhouse roof forward accordingly.

Any takers?

YachtForums · 10-22-2009, 09:27 AM

Well Steve, I just remodeled the picture for you. I reduced it from 2400 pixels to 640 pixels in width, as per our guidelines. Please read our rules before posting again. I will not reduce the next one. I'll remove it.

steveinjeddah · 10-22-2009, 09:32 AM

Quote:

Originally Posted by YachtForums

Well Steve, I just remodeled the picture for you. I reduced it from 2400 pixels to 640 pixels in width, as per our guidelines. Please read our rules before posting again. I will not reduce the next one. I'll remove it.

Duly noted. Sorry about that. Thanks for your help.

Mov-it! · 10-22-2009, 04:51 PM

A pair of line drawings or a bigger file would be practical

SeaEric · 10-22-2009, 05:13 PM

Do you mean like this:?

SeaEric · 10-22-2009, 05:24 PM

While you're at it, extending the aft shearline and deck canopy would be nice too. Don't you just love photo editing software? Even an idiot yacht broker like me can make yacht design modifications!

steveinjeddah · 10-24-2009, 12:19 AM

Great job SeaEric. Exactly what I was looking for. Now I've got something to kickstart the conversation.

Apache2k · 11-18-2009, 02:31 PM

I could make u a 3d model of this if you dont have the original, but I would need more images
